Ultra HD 4K Camera
• Ultra HD 4K camera
• 30 frame rate
• 3x e-PTZ camera
•Field of View: 120
Audio Features
• Tabletop Speakerphone CP900
- 2 meters voice pickup radius
- six-beamforming microphone array
- Call control synchronization
Audio Technology
• Acoustic echo cancellation
• Automatic gain control
• Yealink Noise Proof Technology
Operating System
• Based on Android 9.0
Meeting Features
• Calendar
• One-click join
• Proximity join
• PSTN dial-in
• Meeting collaboration
- Content sharing
- Whiteboard
• Meeting control:
- Add participates
- Hold/Resume
- Camera On/Off
- Mute/Unmute
- Volume Up/Down
- Hang up
Video Standard and Network Suitability
Video codecs: H.264 High profile, H.264, SVC-T
• Anti video packet loss
• Bandwidth dynamic adaptive adjustment
Network and Security Features
• Built-in dual-band Wi-Fi (2.4GHz/5GHz)
• Built-in Bluetooth
• IPv4 and IPv6, DHCP/static IP
• HTTP/HTTPS web server
• SRTP/TLS, AES 256-bit encryption
• QoS: 802.1p/q, Diff-serv
• VLAN, LLDP
• IEEE802.1X
- EAP-MD5/EAP-TLS
- PEAP-MSCHAPv2
- EAP-TTLS/EAP-MSCHAPv2
• Network diagnosis: Ping, Trace route
• Time and date synchronization using SNTP
• Built-in certificate
Configuration Management
• Configuration via
- Display
- Browser
- Auto-provisioning
- Teams admin center Portal
• Virtual remote control
• Firmware upgrading
• Factory resetting
• Export or import configuration
• Export system log
VC210 Connection
1 x HDMI output (CEC supported)
• 1 x 10/100M Ethernet port:
Power over Ethernet (IEEE 802.3af)
• 2 x USB 2.0
• 1 x Line-out (3.5mm)
• 1 x security lock slot
• 1 x reset slot
Other Physical Features
• Color: Space Silver
• Capacity: 16GB (Available: 8GB)
• Yealink PoE Adapter: AC 100~240V input
Power consumption (PSU):
Idle＜6.5W; Normal: 7W; MAX: 8W
• USB Output: 5V 500mA
• Dimension (W.D.H):
- VC210: 300mm x 70mm x 86.6mm
- VCR20-MS: 147.6mm x 42.3mm x 15.8mm
• Operating humidity: 10~95%
• Operating temperature: 0~40°C
• Storage temperature: -30~70°C
VC210-Teams
• VC210 Collaboration bar
• VCR20 Remote controller
• Privacy shutter
• 1.8m HDMI cable
• 2m Network cable
• 3m Network cable
• Quick Start Guide
• Power adapter
CP900 Room
• Tabletop Speakerphone CP900
• 5m USB EXT cable
VC210-CP900-Teams Package
Package contents:
- VC210-Teams
- CP900 Room
• Qty/CTN: 4PCS
• N.W/CTN: 11.0kg
• G.W/CTN: 12.0kg
• Giftbox size: 377mm*246mm*190mm
• Carton Meas: 528mm*397mm*426mm
