מצלמה
|
Image Sensor
1/3" Progressive Scan CMOS
Max. Resolution
2560 × 1440
Min. Illumination
Color: 0.005 Lux @ (F1.2, AGC ON)
Shutter Time
1/3 s to 1/100,000 s
|
|
עדשה
|
Focal Length & FOV
2.8 mm: horizontal FOV: 98°, vertical FOV: 53°, diagonal FOV: 115°
Lens Mount
M12
Iris Type
Fixed
Aperture
2.8 mm: F2.0
|
|
עששה
|
Mini
|
|
עדשה קבועה
|
Iris Type Fixed
|
|
וידאו
|
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50 Hz: 1 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
60 Hz: 1 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Baseline Profile/Main Profile/High Profile
H.265 Type
Main Profile
Bit Rate Control
CVR/BVR
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Region Of Interest (ROI)
Support 1 fixed region for main stream
|
|
אודיו
|
Audio Type Mono
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC)
Audio Sampling Rate 8 kHz/16 kHz/32 kHz
Environment Noise Filtering Yes
|
|
רשת
|
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Simultaneous Live View Up to 15 channels
API Open Network Video Interface, ISAPI, SDK, ISUP 5.0
User/Host Up to 32 users
3 level: administrator, operator, and user
Network Storage NAS (NFS, SMB/CIFS)
Client iVMS-4200, Hik-Connect
Web Browser Plug-in required live view: IE10, IE11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
|
|
תמונה
|
Image Parameters Switch
Yes
Image Settings
Saturation, brightness, contrast, and sharpnes adjustable by client software or web browser
Day/Night Switch Day, Night, Auto, Schedule
Wide Dynamic Range (WDR) 120 dB
Image Enhancement BLC, HLC, defog, 3D DNR
Privacy Mask Yes
|
|
ממשק
|
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support MicroSD/MicroSDHC/MicroSDXC card, up to 256 GB
Audio 1 input (line in), 1 output (line out)
Alarm 1 input, 1 output (max. 12 VDC, 30 mA)
RS-485 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Key Yes
|
|
ארוע
|
Basic Event
Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconncected), video quality diagnosis
Smart Event
Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection
Audio exception detection, defocus detection, scene change detection
Linkage
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning
|
|
כללי
|
Power
12 VDC ± 20%, 0.25 A, max. 3 W, two-core terminal block
PoE: 802.3af, Type 1, Class 3, 36 V to 57 V,0.1 A to 0.07A, max. 3.65 W
Dimension
Main body: 77.5 mm × 69 mm × 26 mm (3.1" × 2.7\" × 1.0\")
L30: Ø26 mm × 50 mm (Ø1.0 × 2.0\")"
Package Dimension
Kit/Main body: 254 mm × 164 mm × 130 mm (10" × 6.5\" × 5.1\")
Camera: 219 mm × 139 mm × 100 mm (8.6 × 5.5\" × 3.9\")"
Main body: approx. 90 g (0.2 lb.)
Camera: approx. 90 g (0.2 lb.)
With Package Weight
Main body: approx. 456 g (1.0 lb.)
Package (with 8 m cable): approx. 991 g (2.2 lb.)
Package (with 2 m cable): approx. 776 g (1.7 lb.)
Camera (with 8 m cable): approx. 676 g (1.5 lb.)
Camear (with 2 m cable): approx. 451 g (1.0 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
18 languages: English, Traditional Chinese, Russian, Turkish, Japanese, Korean, Thai, Vietnamese, Estonian, Bulgarian, Hungarian, Czech, Slovak, French, Italian, German, Spanish, Portuguese
General Function
One-key reset, heartbeat, mirror, password protection, privacy mask, rotate, watermark, IP address filter
Length Of Lens Cable
2m (6.6 ft.) and 8 m (26.2 ft.) optional
|
