מפרט
|
CPU Intel Xeon D-1541 8-core 2.1GHz, burst up to 2.7GHz
Hardware encryption engine Yes (AES-NI)
Memory 8 GB DDR4 ECC UDIMM, expandable up to 64GB
Compatible drive type 16 x 3.5/2.5" SATA HDD/SSD
External ports • 2 x USB 3.0 port
• 2 x Expansion port
Size (HxWxD)
• 132.3 x 430.5 x 624.5 mm
• 132.3 x 482 x 656.5 mm (with server ears)
• 3RU
Weight 17.4 kg
LAN • 2 x 10GbE RJ45 (10GBase-T)
• 4 x 1GbE RJ45
PCIe 3.0 slot • 2 x 8-lane x8 slot
• High-performance network interface card support
Scheduled power on / off Yes
System fan 3 (80 x 80 x 32 mm)
AC input power voltage 100V to 240V AC
Power frequency 50 to 60Hz, single phase
Operating temperature 5°C to 35°C (40°F - 95°F)
Storage temperature -20°C to 60°C (-5°F to 140°F)
Relative humidity 5% to 95% RH
Maximum operating altitude 5,000 m (16,400 ft)
|
|
כללי
|
Networking protocol CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™, L2TP)
File system • Internal: Btrfs, ext4
• External: Btrfs, ext4, ext3, FAT, NTFS, HFS+, exFAT3
Storage management
• Maximum single volume size: 108TB / 200TB (at least 32GB RAM required, for RAID 5 or RAID 6 groups only)
• Maximum internal volumes: 1,024
• Maximum iSCSI Targets: 128
• Maximum iSCSI LUNs: 512
• iSCSI LUN clone / snapshot support
Supported RAID type Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
File sharing capability
• Maximum user account: 16,000
• Maximum user group: 512
• Maximum shared folder: 512
• Maximum concurrent CIFS / AFP / FTP connections: 2,048
Privilege Windows Access Control List (ACL)
Virtualization VMware vSphere® 6, Microsoft Hyper-V®, Citrix®, OpenStack®
Directory service Windows® AD integration: Domain users login via Samba (CIFS) / AFP / FTP / File Station, LDAP integration
Security FTP over SSL / TLS, IP auto-block, firewall, encrypted network backup over Rsync, HTTPS connection
Utilities Synology Web Assistant, Cloud Station Drive, Cloud Station Backup, Cloud Sync Decryption Tool, Evidence Integrity Authenticator,
Photo Station Uploader, Snapshot Manager for VMware, Snapshot Manager for Windows, NFS Plug-in for VMware VAAI
Supported clients Windows 7 onward, Mac OS X® 10.10 onward
Supported browsers Chrome®, Firefox®, Internet Explorer® 9 onwards, Safari® 8 onwards; Safari (iOS 7 onwards), Chrome (Android™ 4.0 onwards) on tablets
|
|
יישומים
|
File Station Virtual drive, remote folder, Windows ACL editor, compress / extract archived files, bandwidth control for specific users or groups,
creating sharing links, transfer logs
Backup solutions Network backup; local backup; desktop backup; configuration backup; OS X Time Machine; backup data to public cloud;
shared folder sync - maximum task number: 32
FTP Server Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL / TLS and SFTP protocol, boot over the
network with TFTP and PXE support, transfer logs
High Availability Manager Combines two RS4017xs+ into one high-availability cluster
Security Advisor Malware detection / removal, user account / password, network, system-related security scan
iOS / Android™ applications DS cloud, DS file, DS finder, DS cam, DS note, MailPlus, Chat
Windows Phone® applications DS file, DS finder
|
|
חבילות תוספות
|
Antivirus Essential Full system scan, scheduled scan, white list customization, virus definition auto update
Chat Messaging service that runs locally, ensuring sensitive corporate information remains safely stored on company premises while providing
users usability equivalent of public cloud services. Built to work with Office and Calendar seamlessly.
Cloud Station Suite Default concurrent file transfers: 2,000, retain historical and deleted file versions
Cloud Sync
One or two-way synchronization with public cloud storage providers including Amazon Cloud Drive, Amazon S3-compatible storage,
Baiduyun, Box, Dropbox, Google Cloud Storage, Google Drive, hubiC, Megafon Disk, Microsoft OneDrive, OpenStack Swift-compatible
storage, WebDAV servers, Yandex Disk
Log Center SSL connection, log rotation: 6 months, 1 year, 2 years, 3 years, email notification
MailPlus Intuitive webmail interface for MailPlus Server; customizable mail labels, filters and user interface
MailPlus Server Secure, reliable, and private mail solution with high-availability, load balancing, security and filtering design (Includes 5 free email account
licenses, additional accounts require the purchasing of additional licenses)
Note Station Rich-text note organization and versioning, encryption, sharing, media embedding and attachments
Office Real-time collaboration on your private cloud. Work seamlessly together on documents and spreadsheets on your secured company network
while combining the convenience and usability of a public cloud service.
Storage Analyzer Volume and quota usage, total size of files, volume usage and trends based on past usage, size of shared folders, largest / most / least
frequently modified files
Surveillance Station Maximum IP camera: 90 (total of 2,700 FPS at 720p, H.264)
(Includes two free camera licenses, additional cameras require the purchasing of additional licenses)
VPN Server Maximum connections: 30; supported VPN protocol: PPTP, OpenVPN™, L2TP
Web Station Virtual host (up to 30 websites), PHP / MariaDB®, 3rd-party applications support
Other packages Additional 3rd-party packages are available on Package Center
|
|
סביבת עבודה
|
Environment safety RoHS compliant
Package content
• RS4017xs+ main unit
• Quick Installation Guide
• Accessory pack
• 2 x AC power cord
Optional accessories
• 8GB / 16GB DDR4-2133 ECC UDIMM (RAMEC2133DDR4-8G / RAMEC2133DDR4-16G)
• Synology E10G17-F2 / E10G15-F1 10Gbps Ethernet adapters
• Synology Expansion Unit RX1217/RX1217RP
• Synology RKS1317-Rail Kit Sliding
• Synology Surveillance Video Decoder VS360HD
• Surveillance Device License Pack
• MailPlus License Pack
• Docker DSM License Pack
Warranty 5 years
|
